Twin Augers A520ST
The Anderson pull type A520 twin auger mixer (side trap discharge) has the ability to mix the widest variety of ingredients. Process large amount of hay, even complete square and round bales of baleage. Available with several discharge options. Whether your rations are designed to increase milk production of dairy cows... + Read More
Features
- Capacity of 520 ft³ (14.7 m³ )
- HP PTO Requirement in low speed: minimum 80 HP in high speed: minimum 120 HP
- Height of 102 in (2.59 m) 120 in (3.05 m) with extension
- Unloading the material by side trap or front conveyor
- 2 augers with 6 reversible knives each in carbide tungsten (10 knives per auger, optional)
Specs
| Capacity | |
| Capacity (no capacity extension) | 520 ft3 (14.7 m3) |
| 6 in capacity extension | 574 ft3 (16.3 m3) |
| 12 in capacity extension | 628 ft3 (17.8 m3) |
| 18 in capacity extension | 682in(208cm) ft3 (19.3 m3) |
| Number of Auger | 2 |
| Dimensions | |
| Length (A) | 242 in (6.15 m) |
| Height (B) no extension | 102 in (2.59in(150cm) m) |
| 6 in capacity extension | 108 in (2.74 m) |
| 12 in capacity extension | 114 in (2.9 m) |
| 18 in capacity extension | 120 in (3.05 m) |
| Hay retention ring (additionnal height) | 0 in / 3,5 in |
| Width (C) | |
| Without incline conveyor | 101 in (2.57 m) |
| With incline conveyor (retracted) | 115 in (2.92 m) |
| Incline conveyor operating angle (degrees) | 226 @39 degrees |
| Outside width of the wheels | 99 in (2.51 m) |
| Lateral distance to discharge point (D) | |
| Incline conveyor chain / belt 3 ft at min.26 angle /max 40 | 29-22in at 26º / 27-20in at 40º |
| Incline conveyor chain / belt 4 ft at min. 26 angle /max 40 | 38-42in at 26º / 51-51in at 40º |
| Incline conveyor chain / belt 5 ft at min. 26 angle /max 40 | 44-48in at 26º / 61-61in at 40º |
| Incline conveyor chain / belt 6 ft at min. 26 angle /max 40 | 48-52in at 26º / 67-67in at 40º |
| Incline conveyor chain / belt 7 ft at min. 26 angle /max 40 | 54-58in at 26º / 77-77in at 40º |
| Incline conveyor chain / belt 8 ft at min. 26 angle /max 40 | 58-62in at 26º / 84-84in at 40º |
| Discharge height (E) | |
| Incline conveyor chain / belt 3 ft at min. 26 angle /max 40 | 34-38in at 26º / 44-44in at 40º |
| Floor ST (E1) / Conveyor FD (E2) to ground | 34 in (0.85 m) |
| Specifications | |
| PTO shaft - Standard specification | 540 RPM 1" 3/8 Z6 |
| PTO shaft - Option specification | 1000 RP m 1" 3/8 Z21 |
| 2 speed Gear Box | Optional |
| 2 Speed Gear Box and ratio | C3A-R, 1;1,5 54in(888cm)0 RPM C3A-R, 1,8;2,7 1000 RPM |
| Minimum PTO HP Requirement - Low Speed | 80 |
| Minimum PTO HP Requirement - High Speed | 120 |
| Auger RPM - Low Speed | 27 RPM |
| Auger RPM - Standard High speed | 41 RPM |
| Standard planetary model and ratio configuration | 1602 @13.4 |
| Optionnal Planetary | N/A |
| Floor Thickness (AR235 grade or equivalent) | 5/8 in |
| Sidewall Thickness (AR235 grade or equivalent) | 1/4 in |
| Flighting Thickness (AR235 grade or equivalent) | 5/8 in |
| Standard knives per auger | 6 / 10 optional |
| Driveline security | Shear bolt |
| Hydraulic flow requirement | 10-15 US gal/ m in 37-56 L/ m in |
| Hydraulic pressure | 160-200 bar (2300-2900 psi) |
| Load cell | 3 |
| Scale system | DG500 (standard) |
| Machine Weight (empty) - STD configuration | 11 744 lb (5326 kg) |
| Utility load capacity | 15 080 lb (6839 kg) |
| Axle - Standard specifications | Single |
| Axle - Optional specifications | N/A |
| Wheels - Standard specifications | 385/65R22.5-20 |
