XLB 10
Overview:
Loftness is North America’s leading brand of grain baggers, and the XLB10 is the most fully featured grain bag loader on the market. It’s engineered for larger bag capacity, easier bag loading, improved transport and more. Not to mention, it’s made in the U.S.A. with standard parts and supported by a large North American dealer network. So when you compare it with anything else available, the XLB10 is clearly the bigger, better bagger.
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Loan Calculator
Use the Loan Calculator to help you determine the financing and payment options that are best for you.
**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. This information is provided for illustrative purposes only and does not constitute an application.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Features
- Loads 10-Foot-Diameter Grain Bags up to 500 Feet
The XLB10 has a specialized tunnel and bag pan to accommodate 10-foot-diameter bags that are up to 500 feet long. This allows approximately 22,000 bushels of storage per bag. - Jib Crane and Trolley System
Powered by 12-volt electric motors, the jib crane and trolley system makes it easier than ever to load bags onto the machine. Simply use the remote control to lift the bag off the ground and slide it into place on the tunnel. - Bag Loading Apron
The electric-powered bag loading apron assists in pulling the bag into place. This feature reduces the amount of labor required to load bags, while helping ensure proper bag positioning on the pan. - Remote Control
The XLB10 grain bag loader comes standard with a remote control. It allows you to wirelessly control the jib crane, trolley and bag loading apron. - Bag Tray Adjustment Winch
Ensure the grain bag fits properly by making slight adjustments with the adjustment winch. - Transport Wheels
Transport wheels can be hydraulically raised and lowered to move from one location to the next. Not only does this simplify the transport process, but it also eliminates the need to relieve pressure from the traction wheels when moving the machine. - Traction Tires
The 12.5L 15-inch Sure Grip traction tires have a chevron-style tread for maximum grip. - Disc Brakes
The traction wheels are equipped with extra-large automotive style disc brakes, giving you confident control over the bagging process. - Hand Wheel
The hand wheel controls the master brake cylinder. It allows slight, precise brake pressure adjustment to both traction wheels simultaneously, helping to ensure the bag loads in a straight line. Pressure is displayed via a large liquid-filled pressure gauge mounted next to the control wheel. - High-Flow Auger
With its 20-inch primary auger, the XLB 10 can transfer grain at rates up to 30,000 bushels per hour. The auger features a 2-inch shaft and heavy-duty bearings for fast, reliable grain loading that keeps up with the speed of harvest, even with multiple combines running. - Extra-Large Hopper
The extra-large hopper is an easy target for dumping grain. It also accommodates loading from both sides of the machine at once. - Hydraulic Assist Height Adjustment
The hydraulic lift system is designed around a heavy-duty axle and powered by a 4-by-8-inch cylinder. - Easy Access Platforms
No more climbing ladders. The XLB10 grain bag loader has skid-resistant platforms on the left- and right-hand sides for convenient, safe access to the top of the bag tunnel when installing bags on the machine. - Auger Clean-Out Door
When you’re finished using the grain bagger, use the easy-access door to clean grain out of the auger. - Grain Sampling Port
Take periodic samples while loading your grain bags. The new grain sampling port provides easy access for pulling grain samples. - Fold-Up Hitch
A fold-up hitch allows compact storage of the grain bag loader. The hitch comes complete with a leveling ratchet and bulldog jack. - Safety Warning Lights
Proper lighting is included for safe road transport. - 85 HP/540 PTO RPM Requirement
- Optional Work Light Kit
Don’t let the dark slow down your bagging operation. The optional work light kit includes three magnetically mounted LED lights, each producing 2,400 lumens. - Optional Roll Tarp
Roll top covers are fast, simple and smooth. The one-man operation of the roll top canvas is done from the ground, through the permanently mounted and storable extension crank. The rolled-up tarp stores neatly out of the way. It can be supplied by ACI or Shur-co. - Optional Truck Unloading Auger
Load grain bags from grain trailers and semis with the 10-Foot Truck Unloading Auger.
Specifications
| Model Number | XLB 10 |
| Operating Weight | 4,800 lbs |
| Operating Dimensions | |
| Length | 18' 1/2" (5.5m) |
| Width | 13' 1" (4m) |
| Height | 11' (3.4m) |
| Hopper Dimensions | 7' 4" x 10' 5" (2.2m x 3.1m) |
| PTO | |
| RPM | 540 |
| Horsepower | 85 |
| Shaft Size/Type | 6-B Spline |
| Make/Model | Weasler 35R |
| Auger | |
| Primary Auger | 20" diameter (0.5m)/385 RPM |
| Transfer Capacity | 30,000 Bushels/hr |
| Wheels/Tires | |
| Op. Wheels/Size/Type | 33" 12.5L-15 SureGrip |
| Transp. Wheels/Size/Type | 11L-15 10 ply |
| Bag Handling Capacity | |
| Diameter | 10' Bags |
| Max. Length | 500' |
