Manitou MLA 6-65 H-Z

Double tap to zoom

MLA/MLA-T

MLA 6-65 H-Z

Overview:

Static tipping load with forks (straight): 4980 lb
Static tipping load with bucket (straight): 6409 lb
Max. height of bucket pivot point: 10 ft 11 in
Engine power (kW): 48.50 kW

Get a Quote

Send to a Friend

Payment Calculator

Get A Quote

Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

Loan Calculator

Use the Loan Calculator to help you determine the financing and payment options that are best for you.

**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. This information is provided for illustrative purposes only and does not constitute an application.

Send To A Friend

Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

Share This Product:

Features

The MLA 6-65 is a wheel loader that combines reduced dimensions with true power. The hydrostatic transmission gives you performance on every terrain without compromising the smoothness for working in confined spaces. The lift arm has a Z-kinematic for higher break-out forces and provides additional dump height and reach. The machine is designed with the comfort for the operator in mind. All controls are centralized around the joystick and on the floating armrest. With full 360° visibility, an adjustable workspace and ergonomic controls, the machine will host the operator for many hours per day.

Specifications

Capacities
Static tipping load with bucket (straight)	6409 lb
Static tipping load with bucket (full turn)	4916 lb
Static tipping load with forks (straight)	4980 lb
Static tipping load with forks (full turn)	3920 lb
Max. height of bucket pivot point	10 ft 11 in
Max. lifting height (below forks)	10 ft 3 in
Breakout force with bucket	5743 daN
Weight and dimensions
Unladen weight (with forks) with 4-post canopy	9149 lb
Unladen weight (with forks)	9500 lb
Wheelbase	6ft 7 in
Overall width of 4 posts canopy	4 ft 2 in
Overall cab width	4 ft 2 in
Overall height with FOPS removed and ROPS folded	6 ft 6 in
Overall height with 4 posts canopy	8 ft 1 in
Overall height with cab	8 ft 1 in
Tilt-up angle	45 °
Tilt-down angle	45 °
Articulation angle	45 °
Overall width less bucket	5 ft 5 in
Overall length - Less Bucket	14 ft
Ground clearance	1 ft 3 in
Engine
Engine brand	Yanmar
Engine model	4TNV98CT_PGWL1
Engine norm	Stage V
Number of cylinders / Capacity of cylinders	4 - 201 in³
Engine power (Hp / kW)	65 Hp / 45.50 kW
Max. torque / Engine rotation	207 ft/lbs / 1560 rpm
Engine cooling system	2 radiators water + hydraulic oil
Transmission
Transmission type	Hydrostatic
Number of gears (forward / reverse)	2 / 2
Max. travel speed (may vary according to applicable regulations)	19 mph
Travel speed (laden)	12 mph
Differential lock	Front and rear locking of the machine
Parking brake	Manual
Service brake	Hydraulic drum brake on front axle, acting on all 4 wheels
Hydraulics
Hydraulic pump type	Gear pump
Hydraulic flow - Pressure	18 US gpm / 2901 PSI
High-Flow Option (l/min)	26 US gpm
Drive hydraulic system pressure	6092 PSI
Tank capacities
Hydraulic oil	20 US gal
Fuel tank	25 US gal
Noise and vibration
Vibration on hands/arms	8 ft/s²
Miscellaneous
Cab certification	ROPS - FOPS cab (level 1)
