Manitou VJR 26

Double tap to zoom

VJR Aerial Platforms

VJR 26

Overview:

Maximum outreach: 10 ft 4 in
Overhang: 21 ft 11 in
Platform capacity: 441 lb
Number of people (indoor): 2

Get a Quote

Send to a Friend

Payment Calculator

Get A Quote

Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.

Loan Calculator

Use the Loan Calculator to help you determine the financing and payment options that are best for you.

**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. This information is provided for illustrative purposes only and does not constitute an application.

Send To A Friend

Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.

Share This Product:

Features

Perform high precision work with the Manitou VJR 26. This electric, compact MEWP can accommodate two operators. Equipped with a perforated floor and a double rail, the workplatform is ideally suited to industrial requirements. Also take advantage of 350 degree rotation for more flexibility and make quicker job placement adjustments as needed. The VJR 26 mast lift brings you comfort and security regardless of your business constraints. The simplified maintenance of the equipment ensures excellent performance throughout its life.

Specifications

Capacities
Floor height (access)	1 ft 8 in
Platform height	25 ft 9 in
Max. outreach	10 ft 4 in
Overhang	21 ft 11 in
Pendular arm rotation (top / bottom)	+58 ° / -56 °
Platform capacity	441 lb
Number of people (indoor / outdoor)	2 / 1
Weight and dimensions
Platform weight*	5842 lb
Platform dimensions (length x width)	3 ft 8 in x 3 ft 1 in
Overall length	9 ft 2 in
Overall width	3 ft 3 in
Overall height	6 ft 6 in
Jib length	4 ft 9 in
External turning radius	6 ft 10 in
Ground clearance under pothole protection	1 in
Ground clearance at centre of wheelbase	4 in
Wheelbase	3 ft 11 in
Performances
Drive speed - stowed	3 mph
Drive speed - raised	0.40 mph
Gradeability	25 %
Permissible leveling	2 °
Wheels
Standard tires	16.5-11 1/4 / 406 x 127 mm
Drive wheels (front / rear)	0 / 2
Steering wheels (front / rear)	2 / 0
Braking wheels (front / rear)	0 / 2
Engine/Battery
Electric Pump	3 kW
Number of hydraulic pump / Capacity of hydraulic pump	2 x 0.26 in³
Battery voltage	24 V
Battery capacity	250 Ah
On-board charger (V / A)	24 V / 30 mA
Miscellaneous
Number of cycles with STD Battery (HIRD)	29
Ground Pressure	171 PSI
Hydraulic Pressure	2031 PSI
Hydraulic tank capacity	6 US gal
Vibration on hands/arms	< 0.50 m/s²
Standards compliance
This machine is in compliance with:	ANSI A92.20-2018 CSA B354.6 ICES-002-Issue 6 Standard Canadian EMC
