Overview:
Get A Quote
Fields with asterisks* are required. Please email our helpful staff with any questions or comments using the contact form.
Loan Calculator
Use the Loan Calculator to help you determine the financing and payment options that are best for you.
**The accuracy of this calculator and its applicability to your circumstances is not guaranteed. This information is provided for illustrative purposes only and does not constitute an application.
Send To A Friend
Fields with asterisks* are required. Your friend will receive an email that contains a reference to this page. Please send this email only to people you know who would be interested in this information.
Features
Commercial Grade Power
Commercial Grade Power Briggs & Stratton® CXi Series engines are built for extreme conditions with an advanced debris management system and beefed-up cylinder block structure.
Operator Convenience
Ergonomic riding mower control panel features cup-holder and fuel gauge.
Patented Suspension System
Pivoting front axle plus small shocks and medium rear shocks allows the wheels to follow the ground and improve comfort in a wide variety of conditions.
Exceptional Performance
The well-tuned steering system delivers smooth and confident operation for excellent performance time after time.
Integrated Transmissions
Commercial Hydro-Gear® ZT-3200® (Not shown) transaxles are designed for high performance and are fully serviceable.
Easy Access
Quick removal of the floor pan provides convenient access to the top of the deck for easy cleaning and service.
Protection
Heavy-duty bumper protects the engine while also allowing for easy service access.
Mower Spindles
Cast-aluminum greaseable spindles feature 1” shaft with 2.5” x 1” dual ball bearings with top access grease fittings and pressure relief valve.
Cut Height
Foot-operated deck lift, with adjustable pedal, can change cut height in 1/4" increments from 1.5"- 4.5".
Acres Per Hour
Mows up to 4 acres per hour, based on 80% efficiency.
Miles Per Hour
Forward ground speed up to 10 mph, reverse 5 mph.
Specifications
| Model Number | 5901911 |
| Engine Brand | Kawasaki® FS691V |
| Engine Power Rating * | 23 |
| Displacement (cc) | 726 |
| PTO | Electric |
| Cylinders | 2 |
| Starter | Electric |
| Fuel Type | Gasoline |
| Fuel Tank Capacity (gal) | 5.5 |
| Hour Meter/Instrumentation | Dual-function hour meter, fuel level gauge in tank |
| Cutting Width (in) | 52 |
| Cutting Height (in) | 1.5 - 4.5 |
| Spindles | Aluminum Greaseable |
| Deck Construction | 10-gauge fabricated |
| Suspension | Adjustable front and rear coil-over-shocks with pivoting front axle and a rear swing-arm with large adjustable coil-over-shocks |
| Transmission | Dual commercial Hydro-Gear® ZT-3200® transaxles with 7" cooling fans |
| Drive Axles (in) | 1.125 |
| Caster Tires (in) | 13 X 6.5-6 |
| Drive Tires (in) | 22 X 11-10 |
| Ground Speed-Fwd (mph) | 0-10 |
| Ground Speed-Rev (mph) | 0-5 |
| Overall Length (in) | 80 |
| Overall Width (in) Deflector Down/Deflector Up | 66.75/56.5 |
| Dry Weight (lbs) | 964 |
| Seat Package | Mid-back seat with arm rests |
| Certified Roll-over Protection System | 180° Foldable |
| Controls / Safety Group | Adjustable twin fold out 1" tubular steering levers with comfort grip |
| Parking Brake / Safety Circuit | Hand-operated internal transaxle brake |
| Engine Configuration | Kawasaki® |
Accessories/Attachments
<p>Light Kit<br>Select models are pre-wired for simple installation.</p>
<p>Mulch Kit<br>Select kits include dedicated mulching blades, baffels, hardware and instruction sheet.</p>
<p>Trailer Hitch Kit<br>Will accept a 1/2” shank ball and comes complete with hardware.</p>
<p>Flat-Free Caster Tires<br>Run all day with no flats, eliminates down time. Standard on select models.</p>
<p>LED Light Kit<br>Energy efficient heavy-duty ROPS mounted LED light kit with simple instructions.</p>
<p>Lawn Striping Kit<br>Rubber flap system lays down clippings to create eye catching grass patterns across the landscape.</p>
<p>Service Jack<br>Heavy-duty steel bracket and jack allows for easy and convenient access under the deck.</p>
